This 4X4 MIMO DUAL-BAND is a WiFi omnidirectional antenna with a gain of 6dBi in the 2.4 GHz and 8dBi in the 5 GHz frequency band.
The omnidirectional antenna is applications using 802.11ac / Wave2 / MU-MIMO standard.
This model is therefore very versatile and suitable for illuminating medium-sized areas.
The antenna is made of robust, weatherproof, UV-resistant PVC and is suitable for indoor and outdoor use. It has four N female connectors.
| Electrical | ||
| Frequency Range | 2400-2500MHz X2 | 5150-5800MHz X2 |
| Gain | 6dBi | 8dBi |
| Polarization | Vertical / Horizontal | Vertical / Horizontal |
| V.S.W.R | ≤1.5 | ≤2.0 |
| Radiation | Omni-Direction | |
| Horizontal Beam width | 360° | |
| Vertical Beam width | 40° | 17° |
| Lightning Protection | DC Grounded | |
| Maximum Input Power | 50W | |
| Impedance | 50Ώ | |
| Connector | 4xN Female | |
| Antenna Radome Material | PVC | |
| Mount way | Pole | |
| Diameter of Installation Pole | Ø30~Ø50mm | |
| Mechanical | ||
| Dimensions | Φ165x320mm | |
| Weight | 2KG | |
| Operating Temperature | -40℃ to+80℃ | |
| Rated Wind Velocity | 60m/s | |
| RoHS Compliant | YES | |
The 4X4 MIMO DUAL-BAND is a WiFi omnidirectional antenna with a gain of 6dBi in the 2.4 GHz and 8dBi in the 5 GHz frequency band.
The omnidirectional antenna is compatible to 256-QAM modulation and applications using 802.11ac / Wave2 / MU-MIMO standard.
The mounting bracket enables simple wall mounting using the supplied screws and wall plugs and mast/rail mounting using the supplied clamps.
